Professional Security Long Range Communication Two Way Radio
Long distance radio communication,with shockproof,waterproof and dustproof,T-850 portable radio is specifical customized for users in industries,which Harsh, noisy and dusty working conditions in megaproject and construction sites may lower your efficiency.
Quick Details
1.10W/5W/2W Power Switch with Side-key operation
2.Chinese/English Voice Announcement
3.Wide/Narrow Bandwidth Selection 12.5KHz/25KHz
4.CTCSS&DCS non-standard code
5.Battery Saver
6.Low Battery Alert
7.Check battery capacity by handheld operation and will annouce the capacity in current status
8.VOX on/off, VOX level setting, VOX delay time setting
9.DTMF/PTT ID
10.Busy Channel Lockout
11.Scan, Auto scan, Priority Channel Scan, Scan Add, Scan Delete
12.TX Power Level Adjustment by hand operation
13.Monitor / Monitor Momentary
14.Squelch level report, Squelch level adjustment
15.TOT function
16.Emergency Alarm
17.2 Tone
18.Remote Kill,Stun,Activate&Revive
19.Tail Tone Eliminate
20.Auto Power Off
21.Wire Clone
22.PC Software Program
Specification
|
GENERAL
|
|
Frequency
Range
|
136-174MHz/400-480MHz
|
|
Operating
Temperature
|
-20℃to +55℃
|
|
Frequency
Combination
|
please
lock frequency synthesize
|
|
Frequency
Stability
|
±2.5ppm
|
|
Memory
Channel
|
16
|
|
Working
voltage
|
7.4V
|
|
Antenna
Impedance
|
50Ω
|
|
Operating
Mode
|
simplex
of co-frequency or alien
|
|
Dimensions
|
122*60*38mm
|
|
Weight
|
232g
|
|
TRANSMIT PART
|
|
RF
power
|
10w
|
|
Modulate
Mode
|
F3E
|
|
Max.Freq.Deviation
|
≤5KHz
|
|
Remain
Wave Radiation
|
＜-60dB
|
|
Transmitting
Current
|
≤1000mA
|
|
RECEIVER PART
|
|
Sensitivity
|
＜0.20uV
(12dB SINAD)
|
|
Squeich
Sensitivity
|
＜0.20uV
|
|
Intermodulation
Antijamming
|
50dB
|
|
Audio
Power output
|
500mW
|
|
Receiving
Current
|
≤100mA
|
|
Squelch
Stangby
|
20mA
|
Long distance radio communication
Service
Package: Each package in gift box; 20PCS in strong carton
Payment: Paypal, Western Union, T/T, LC
Lead time: Sample: 1-3 working days
Wholesales order: 500PCS within in 5-7 days
OEM order: 7-15 days after receiving your deposit and confirm sample package design.
Shipping
Express: door to door service DHL,UPS, FEDEX, TNT and so on.
By air: To destination airport, need to assist clear customs, without door to door service.
By sea: To destination port, need to assist clear customs, without door to door service.
The shipping cost depends on weight and dimension, will recommend the cheapest and safest way according your detail quantity.
Shipping period depend on your location. If deliver by express, it take 3-7 days from China to destination country. Some remote need more 1-3 days.
