Model
|
OLT-CC-80D
|
OLT-CC-150D
|
OLT-CC-225D
|
OLT-CC-408D
|
OLT-CC-800D
|
OLT-CC-1000D
|
|
Inner Size(cm)
(W x D x H)
|
40×50 ×40
|
50×60×50
|
50×75×60
|
60×85×80
|
80×100×100
|
100×100×100
|
|
Outer Size(cm)
(W x D x H)
|
70x95x150
|
105x110x170
|
105x120x185
|
115x140x195
|
155x140x210
|
155x160x210
|
|
Weight(kg)
|
160kg
|
220kg
|
300kg
|
550kg
|
960kg
|
1100kg
|
|
Standard parameter
|
Temp.control method
|
PID temperature humdity balance control
|
|
Temp.Range
|
ModelA:0℃ ~150℃ Model B:-20℃ ~150℃;
Model C:-40℃ ~150℃ Model D:-70℃ ~150℃
|
|
Humid.Range
|
20%~98%RH
|
|
Temp.Uniformity
|
±2℃
|
|
Temp.Fluctuation
|
±0.5℃
|
|
Humid.Uniformity
|
±3%R·H
|
|
Heating Rate
|
≥3℃/min
|
|
Cooling Rate
|
≥1~1.5℃/min
|
|
Cooling Method
|
Air cooled
|
|
Material
|
Inner
|
SUS# 304 stainless steel 1.2mm
|
|
Outer
|
Cold-roll steel sheet with Electrostatic coating or SUS# 304 stainless steel
|
|
Insulation
|
Ultra-fine glass fiber insulation cotton / rigid polyurethane foam
|
|
Configuration
|
Heater
|
Ceramic heater
|
|
Humidifier
|
Stainless steel armour humidifier
|
|
Cooling
|
Mechnical single stage refrigeration
|
|
Compressor
|
Original improted French Tecumseh hermetic compressor
|
|
Other function
|
Running error ; self diagnosis ; breakdown tips ; auto-power off
|
|
Safety protection
|
Protection for compressor
|
Overload protection;overheat protection ; overpressure protection
|
|
Protection for chamber
|
dry burn alarm;water shortage alarm;electric leakage protection;
|
|
Portection for fan
|
Overload protection;phase sequence protection
|
|
Programmable
Controller
|
Brand
|
Standard TATO 7" LCD touch screen , optional Sanwon TEMI series
|
|
Language
|
Standard English interface, other language is opitonal
|
|
Resolution
|
Temperature:0.01℃;Humidity:0.1%R·H
|
|
Program capacity
|
269patterns/ 13450 segments
|
|
Running method
|
Fix mode & program mode
|
