Technical data
| Special features |
Cable made of silicone, PTFE, metal braiding, ceramic probe tip, meets the specification according to AMS2750 E and CQI-9 |
| Operating temperature |
0 to 400 °C |
| Features |
Adjustable spring pressure ensures good heat transfer |
| process connection |
Bayonet fastener |
| Protection fitting |
Stainless steel 1.4571 |
| Areas of application |
Plastics industry, woodworking machines, printing machines |
|
Push-in thermocouples
with bayonet lock
■ for temperatures from 0 to 400°C
■ as single or twin thermocouple
■ good heat transfer through adjustable spring pressure
■ insulated assembly, or joined to protection tube
■ insertion and removal without tools
Push-in thermocouples with bayonet lock are preferred for measuring temperatures in solids, bearings and molding tools, for example in the plastics industry. The special form of the measuring tips makes these temperature probes suitable for use in flat-bottom or cone-shaped bores.
The rugged pressure spring, which also functions as a cable protector, is made from rust
and acid resistant stainless steel 1.4310 and ensures a steady pressure between the
measuring tip and the bottom of the hole. The fitting length can be altered by rotating the
bayonet lock. Bayonet locks and suitable sockets are available in the diameters 12, 14.5,
15 and 16mm.
The measuring insert is normally fitted with thermocouples to EN 60 584 or DIN 43 710.
Versions with two thermocouples are also available.
|
 |
| Stock versions |
Sales No. |
| 901190/10-848-1040-6-175-11-2500/000 |
90/00352190 |
| 901190/10-848-1040-8-175-11-2500/000 |
90/00371309 |
| 901190/10-848-1042-6-175-11-2500/000 |
90/00055784 |
| 901190/10-848-1042-8-175-11-2500/000 |
90/00055785 |
| 901190/20-848-1042-8-240-11-2500/309 |
90/00055792 |
| 901190/30-835-1042-6-175-13-2500/309 |
90/00055806 |
| 901190/40-848-1042-6-175-13-2500/000 |
90/00055804 |
