PVC Coated Flexible Metal Pipe Plastic Making Machine

PVC coated flexible metal pipe plastic making machine is used for coating pvc on G.I pipe / flexible metal conduit.

  • End product
  • Voltage
  • Inverter
  • Dimension(L*W*H)
  • Power(W)
  • Condition
  • Plastic Processed
  • Weight
  • Application
  • Warranty
Facebook Twitter Pinterest LinkedIn 分享
PVC Coated Flexible Metal Pipe Plastic Making Machine Details

Application:Pipe

Plastic Processed:PE PP

Screw Design:Single-screw

Voltage:380V 50HZ 3Phase(Customized)

Dimension(L*W*H):16m*2m*1.8m

Weight:2T

Certification:CE ISO

Automatic Grade:Automatic

Power(W):15KW

Supply Ability:6 Set/Sets per Month


The Composition

No.

Machine Name

Quantity

Remark

1

Vacuum Device

1 SET

Make coating better

2

Main Extruder

1 SET

SHSJ-50mm

3

4meter Water Tank

1 SET

Spray Cooling ways

4

Puller

1 SET

Double Belt

5

Winder / Cutting Machine

1 SET

Single Spool


Parameter
1. The diameter of the flexible metal conduit: 1-10mm
2. Finished coated thickness: 0.5-1mm
3.Suitable raw material : PVC PE etc.
4.Machine dimension : L*W*H=12m*3m*2.3m
5.Producing Speed : 5-15m/ Minutes

We are the most reliable and professional PVC coated machine manufacturer in China, especial for flexible metal conduit,flexible corrugated hoses and stainless steel pipes etc , contact us now.
