Cisco 3850 Series Power Supply - PWR-C1-350WAC overview
Cisco 3850 Series Power Supply - PWR-C1-350WAC 350W AC Config 1 Power Supply for 3850 Series.
The Cisco Catalyst 3850 Series Switches support dual redundant power supplies. The switch ships with one power supply by default, and the second power supply can be purchased at the time of ordering the switch or at a later time. If only one power supply is installed, it should always be in power supply bay 1.
Specification
|
Product Code
|
PWR-C1-350WAC
|
|
Power supply rated maximum
|
350W
|
|
Total output BTU (Note: 1000 BTU/hr = 293W)
|
1207BTU/hr, 350W
|
|
Input-voltage range and frequency
|
100-240VAC,
50-60 Hz
|
|
Input current
|
4-2A
|
|
Output ratings
|
-56V at 6.25A
|
|
Output holdup time
|
16.7 ms minimum at 100VAC
|
|
Power-supply input receptacles
|
IEC 320-C16 (IEC60320-C16)
|
|
Power cord rating
|
10A
|
|
Physical specifications
|
(H x W x D): 1.58 X 3.25 X 12.20 in
Weight: 2.6 lb
(1.2 kg)
|
Similar Items
|
Product Code
|
PWR-C1-350WAC
|
PWR-C1-440WDC
|
PWR-C1-715WAC=
|
PWR-C1-1100WAC
|
|
Power supply rated maximum
|
350W
|
440W
|
715W
|
1100W
|
|
Total output BTU (Note: 1000 BTU/hr = 293W)
|
1207BTU/hr, 350W
|
1517BTU/hr, 440W
|
2465 BTU/hr, 715W
|
3793 BTU/hr, 1100W
|
|
Input-voltage range and frequency
|
100-240VAC,
50-60 Hz
|
-36VDC to -72VDC
|
100-240VAC,
50-60 Hz
|
115-240VAC,
50-60 Hz
|
|
Input current
|
4-2A
|
<8A at -72VDC
<16A at -36VDC
|
10-5A
|
12-6A
|
|
Output ratings
|
-56V at 6.25A
|
-56V at 7.86A
|
-56V at 12.8A
|
-56V at 19.64A
|
|
Output holdup time
|
16.7 ms minimum at 100VAC
|
> 2ms at -48VDC
|
16.7 ms minimum at 100VAC
|
10 ms minimum at 102.5VAC
|
|
Power-supply input receptacles
|
IEC 320-C16 (IEC60320-C16)
|
Terminal strip
|
IEC 320-C16
(IEC60320-C16)
|
IEC 320-C16
(IEC60320-C16)
|
|
Power cord rating
|
10A
|
20A at 100VDC
|
13A
|
13A
|
