QR barcode scanner wired wireless 2.41Ghz bluetooth 4.0 USB three connection way in one I2DBC028

qr reader
1.Trial order acceptable
2.High quality, reasonable
3.Reasonable Price

Facebook Twitter Pinterest LinkedIn 分享
Physical Parameters
Material ABS+PC+TPU
size L*W*H :170mm*97mm*68mm
Power supply DC 5V
Performance Parameters
Support interface USB, USB virtual RS232
Sensor Planar CMOS sensor
Light source Red CCD ,white LED (lighting)
Processor 32-bit ARM MCU
Decoding Capability

1D: Codabar, Code39, Code32, InterLeaved 2 of 5,

 Industrial 2 of 5, Matrix 2 of 5, Code93, Code128, Gs1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, ISSN, GS1 DATABAR(RSS14),

GS1 DATABAR Limited, Gs1databar Expanded

2D: PDF417, QR CODE, MICRO QR,

 DATAMATRIX, AZTEC CODE

Resolution Code39 3mil, QR 8.7mil, PDF417 5mil,PCS45%
Depth of field 5MIL   CODE39:       3--11   CM
13MIL  UPC-A :       4--27   CM
20MIL  CODE39 :      7.5--35 CM
6.7MIL PDF417 :      3.5--9  CM
10MIL  DATAMATRIX:   3--10   CM
15MIL  DATAMATRIX:   3--17   CM
20MIL  QR :         3--21   CM
Scanning Speed 300scans/sec
Scanning Method Manual ,auto-sensing
Scanning area 5 * 5 cm² -- 30 * 30 cm²
Prompting Mode Buzzer ,indicator light (LED)
Printing contrast No lower than 35%
Scanning angle Roll0-360°,pitch±65°,yaw±60°
Environment Parameters
IP Grade IP 54
Operating temperature 0 to 50 ºC / 32 to 122 ºF
Storage temperature 0 to 50 ºC / 32 to 122 ºF
Operating humidity 5 - 95% (non-condensing)
ESD Protection 15KV air discharge
Shock resistance 1.5 free fall on concrete surface
