QSFP-40G-SR-BD Overview
The Cisco quad small form-factor (QSFP) 40-Gbps bidirectional (BiDi) transceiver is a short-reach pluggable optical transceiver with a duplex LC connector for 40 Gigabit Ethernet short-reach data communications and interconnect applications using multimode fiber (MMF). The Cisco QSFP 40-Gbps BiDi transceiver offers customers a solution that uses existing duplex MMF infrastructure for 40 Gigabit Ethernet connectivity. Unlike with other existing 40 Gigabit Ethernet solutions on the market, with the Cisco QSFP 40-Gbps BiDi transceiver customers can upgrade their network from 10 Gigabit Ethernet to 40 Gigabit Ethernet without incurring any fiber infrastructure upgrade cost.
QSFP-40G-SR-BD Specification
|
Connectors
(for SD)
|
|
|
Left Connector
Type
|
LC multi-mode
|
|
Environmental
Parameters
|
|
|
Min Operating
Temperature
|
50 °F
|
|
Max Operating
Temperature
|
158 °F
|
|
Humidity Range
Operating
|
5 - 95%
|
|
Header
|
|
|
Compatibility
|
PC
|
|
Manufacturer
|
Cisco
|
|
Packaged
Quantity
|
1
|
|
Product Line
|
Cisco
|
|
Brand
|
Cisco
|
|
Interface
Provided
|
|
|
Qty
|
1
|
|
Type
|
40Gb Ethernet
|
|
Connector Type
|
LC multi-mode
|
|
Miscellaneous
|
|
|
Color
|
Gray
|
|
Compliant
Standards
|
FCC CFR21 Part 1040,
GR-20-CORE, IEC 60825-1, RoHS
|
|
Color Category
|
Gray
|
|
Networking
|
|
|
Type
|
QSFP+ transceiver
module
|
|
Form Factor
|
Plug-in module
|
|
Connectivity
Technology
|
Wired
|
|
Data Transfer
Rate
|
40 Gbps
|
|
Data Link
Protocol
|
40 Gigabit Ethernet
|
|
Cabling Type
|
Ethernet 40GBASE-BiDi
|
|
Max Transfer
Distance
|
492 ft
|
|
Optical Wave
Length
|
850 nm
|
|
Service
|
|
|
Support
Details Type
|
Limited warranty
|
|
Support
Details Full Contract Period
|
90 days
|
|
Dimensions
& Weight
|
|
|
Width
|
0.7 in
|
|
Depth
|
2.9 in
|
|
Height
|
0.5 in
|
|
Weight
|
3.53 oz
|
|
Service &
Support
|
|
|
Type
|
90 days warranty
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
