Let Every Drop of Rainwater Full Play Its Value
Rain Water Catchment System Specification:
| Product Name |
Water Catchment System |
| Material |
PP |
| Place of Origin |
Fujian, China |
| Color |
Black |
| Dimension |
L680*W450*H410mm |
| Total Volume |
0.125 CBM/module |
| Weight |
8kg/module |
| Working Temperature |
From -30℃ to +120℃ |
| Pressure Strength |
25tons/sqm |
| HS Code |
3925900 |
| Feature |
Interconnecting Units
Light weight and high strength
Cost effective and eco-friendly
Resistant to acid and alkali
High capacity and high stability
95% void ratio
Space saving
Strong structural design
Straightforward installation
High working efficiency
25 tons/sqm of pressure capability
More than 50 years working life
|
| Application |
Roof Garden
Road Drainage
Water Filtration System
Car Parking Lot
Residential Area
Parkland
Sports Field System
Golf Course
|
| Certificate |
ISO9001:2008 |
Benefits:
1. Harvest rainwater
2. Reduce polluted storm water runoff
3. Protect natural bush lands and creeks
4. Provide and ecologically sustainable storm water system
5. Quick Installation – Reduce site access delays
6. Lightweight – No cranes or lifting equipment required
7. Strong structural design – Designed for car loading
8. Modular – Easily create any shape and size to suite site requirements
9. Maintenance Free Tank – All debris and sediment is removed by pr-filtration
10. Determinate Volume- 95% internal void area
11. Cost Effective – Reduces excavation and disposal by two thirds compared with conventional soak wells.
12. High Infiltration – 90% void surface area
13. Easily Transportable
Detail Pictures:
Brief Introduction about Rain Water Catchment System:
Water Catchment System means the entire process of rainwater collecting. It is becoming increasingly obvious to most governments around the world that the cost of providing a usable water supply is increasing rapidly. Decaying infrastructure and storm water system pollution is not only contaminating ecosystems but this valuable source of water is literally going down the drain. A solution for this problem is Rainwater harvesting, it is the process of collecting, storing, and distributing rainwater from the roof for use in and around the home or office.
Leiyuan Rain Water Catchment System is designed with scientific structure and manufactured using recycled material. It is a lightweight structural component developed through years of research & development. Pressure strength per square meter is 25tons. Plastic modular is ideal for the construction infiltration tanks, re-use tanks, sub surface channels and lightweight void spaces for rooftop gardens, parkland, parking lot, road etc. We are able to produce higher pressure strength products according to customers’ specification.
Project of Rain Catchment System
