Media Type:

Single-Mode Fiber (SMF)

TX Wavelength:

1310 nm.

RX Wavelenght:

1310 nm.

Minimum Optical Budget:

12 dB

Maximum Distance:

10km

Supported Data Rate:

100-2.67Gbps

Supported Applications:

Gigabit Ethernet (1.25 Gbps), 100M Ethernet (100Mbps), 2G Fiber Channel (2.125 Gbps), 1G Fiber Channel (1.0625 Gbps), STM-1 (155Mbps), STM-4 (622Mbps), STM-16 (2.488 Gbps), ODU0 (1.244Gbps), ODU1 (2.498Gbps), OTU1 (2.66Gbps), CPRI option 2 (1228.8 Mbps), CPRI option 3 (2.458 Gbps)

DDM/DOM:

Support

Temperature Range:

Standard 0°-70°C

Connectors:

Double LC

Tx Wavelength Bandwidth:

100 nm (1260-1360 nm)

Rx Wavelength Bandwidth:

100 nm (1260-1360 nm)

Minimum Transmitting Power:

-6 dB

Maximum Transmitting Power:

0 dB

Receiver Sensitivity:

-18 dBm

Receiver Overload:

-3 dBm

Dispersion:

70-100 ps/nm

Transmitter Type:

FP Laser

Receiver Type:

PIN photodiode

Power:

+3.3V single power supply

Chipset:

MAXIM, MINDSPEED, SEMTECH

Compliance:

CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8074i, RoHS, SFP MSA

Transceiver Type:

SFP
