United Energy founded in 2009, National high-tech enterprise,focus on solar panel and solar system R&D obtained more than 100 patents.
Quality is the Company Culture of UNITED ENERGY!
Lead acid is dependable and inexpensive on a cost-per-watt base.Lead acid has a moderate life span, but it is not subject to memory as nickel-based systems are, and the charge retention is best among rechargeable batteries. The lead acid battery works well at cold temperatures and is superior to lithium-ion when operating in subzero conditions.
Electric Parameters:
| Cells Per Unit |
6 Cells |
| Voltage Per Unit |
12V |
| Capacity |
250Ah@10hr-rate to 1.8V per cell @25°C |
| Weight |
70.0 Kg (Tolerancet ±1.5%) |
| Internal Resistance |
Approx. 5.2 mΩ |
| Terminal |
F1 / F2 |
| Max. Discharge Current |
3750A(5s) |
| Design Life |
10~15 years |
| Maximum Charging Current |
62.5A |
| Reference Capacity |
C1 137.6AH
C3 181.0AH
C10 250.0AH |
| Float Charging Voltage |
13.6 V~13.8 V @ 25°℃
Temperature Compensation: -3mV/C/Cell |
| Cycle Use Voltage |
14.2 V~14.9 V @ 25°
Temperature Compensation: -4mV/C/Cell |
| Operating Temperature Range |
Discharge: -20°C~60℃
Charge: 0℃~50℃
Storage: -20C~60℃ |
| Normal Operating Temperature Range |
25°℃±5℃ |
| Self Discharge |
Less than 3% at 25°C per month |
| Container Material |
A.B.S. UL94-HB, UL94-VO Optional. |
Product Advantage:
1, International Certifications, guarantee quality;
2, High Safety: Overvoltage protection; Overcurrent protection; Temperature protection; Short-circuit protection;
3, Higher stability：non-toxic, non-polluting, no rare earth metals, no explosion, no fire.
4, Long service life：10+ years designed lifespan.
5, Full set of certifications.
FAQ: How energy is stored in lead acid battery?
In lead acid battery, energy is stored in the form of chemical energy which is converted into electrical energy. Due to moving of ions, movement of electrons take place and flow of current happens.
