GPS
Frequency range:1575.42MHz
bandwidth:±3 MHz
VSWR:≤1.5
LNA Gain:28dBi
Polarization:RHCP
GSM;UMTS
Frequency range:824MHz~894MHz(AMPS)
880 MHz~960MHz(GSM)
1710MHz~1990MHz;2100MHz(UMTS)
VSWR:≤1.5
Gain:3dBi
Polarization:vertical
Input impedance:50Ω
WIFI
Frequency range:2400-2483MHz
bandwidth:83 MHz
VSWR:≤1.5
Gain:3dBi
Polarization:vertical
