4k Indoor Rental Display P2.6 SMD Stage LED Screen 500x1000 and 500x500
Intelligent monitoring module
Intelligent cabinet with intelligent monitoring (LCD display).
shows the working status, smart monitoring the signal and record the span life.
Perfect design of maintenance
LEEMAN DISPLAY LED’s new generation rental series supports both front and rear maintenance (both module and power supply), saving time and space for customers.
Protection design
To protect both the module and user from accidental damage all cabinet corners are designed with protectable way.
Ultra thin and ultra light
Front maintain cabinet/ Convenient to assemble and disassemble
Use of Special heat dissipation structure make excellent heat dissipation.
Ultra-wide viewing angle give you the largest screen viewing area
Die-cast aluminum cabinet design light and easy to transport.
Datasheet
|
Pixel Configuration
|
SMD2121
|
|
Pixel Pitch（mm）
|
2.604
|
|
Pixel Density（dot/m2）
|
147456
|
|
Module Pixel Matrix （W×H）
|
96x96
|
|
Module Size（mm）
|
250（W）×250（H）
|
|
Module Weight（kg）
|
0.55
|
|
Module Power Consumption Max.（W）
|
45
|
|
Module/Panel（W×H）
|
2×2
|
|
Panel Resolution（W×H）
|
192×192
|
|
Panel Size（mm）
|
500（W）×500（H）
|
|
Panel Weight（kg）
|
7.5
|
|
Maitainence Mode
|
Front/Rear Maitainence
|
|
Panel type
|
Die-case Aluminum
|
|
Brightness（nits）
|
≥1800
|
|
Color Temperature（K）
|
3200—9300
|
|
Viewing Angle（Hor/Vert°）
|
160/160
|
|
Power Consumption Max（W/m2）
|
800
|
|
Power Consumption Avg（W/m2）
|
250
|
|
Operating Power Source
|
AC90~264V，Frequency 47-63（Hz）
|
|
Frame Frequency（Hz）
|
50&60
|
|
Drive Mode
|
Constant Driving，1/32S
|
|
Gray Scale
|
65536
|
|
Refresh Rate（Hz）
|
≥3840
|
|
Gray Scale per Color Level
|
16bit
|
|
Working Temperature/Humidity（℃/RH）
|
-20 – 60 / 10%-85%RH
|
|
Storage Temperature/Humidity（℃/RH）
|
-20 – 60 / 10%-85%RH
|
