Product Name:RFID LF 125khz Access Control Proximity Card Reader
Description
The 125khz reader support EM4305 card read and write operations, while reading the read-only ID card, often used for AGV landmarks, animal tag reading and writing. The EM4305 RF communication protocol is integrated inside the reader. The developer can read and write the card by simply sending a simple command through the communication interface.
MRT-302H RFID Reader is the most powerful series products in Manruta LF family products operating with the low frequency 125Khz~134.2Khz.Besides supporting general EMID (TK4100, GK4100, EM4100) cards reading, Manruta 300 series can read and write low frequency IC chips such as Hitag-S32, Hitag-S256,Hitag-S2048 through efficient decoding algorithm combined with Powerful data processing function of microprocessor. In addition, It can implement the decoding and the making of the animal format tags in accordance with ISO11784/85 protocols.
Manruta-302H is a non-contact IC card reader, it's easy and convenient to operate and reading speed. Its maximum reading distance is up to 6cm.The user-friendly design of DEMO program allows beginners to understand card structure quickly. And user-controlled LED backlight and buzzer reflects the secondary development of the rich features of Manruta ?products.
MRT-302H series readers, in strictly accordance with ISO11784/85 protocols, designed for racing pigeons management, reading and writing electronic ear tag of animals such as pigs, cattle, sheep, rabbits and so on.
Our Advantage
1.Comply with ISO 11784/85 Protocol
2.Support Hitag-S32, Hitag-S256,Hitag-S2048
3.Support the Secondary Development
4.programmer function
5.program the Hitag-S card to EM4100/EM4001/EM4102,ISO11784 FDX-B format
6.backup or duplicate the EM4100 or compatible card
7.customer made the ID card with own or continuous serial no.
8.Physical Interface
USB 2.0
RFID Antenna
Built-in
Frequency:125Khz~134.2Khz (LF )
Operating System
Microsoft Windows2000/XP/Vista/WIN 7
Read / Write Distance
3 ~ 10CM (Depending On The Antenna Structure And The Use Of The Environment)
Power:5 Ma (Typical) Standby
90 Ma (Typical) Field Scanning
5V (Typical) Operation
Shape:123 * 88 * 25 (mm)
About 100g
Three-color LED
Built-in Buzzer
Application
Bars, KTV, Restaurant
Hotel Access, Water/Electric/Gas Power Card Issuers and Recharge
ID Card Key Backup
Animal Management
