It uses an aluminum alloy shell and uses 1008 RGB LEDs as the light source.It is divided into 112 segments,9 per segment,and RGB of each segment can be individually controlled RGB to achieve dynamic patterns,letters,and number.It is the most popular LED strobe of matrix mode in the club at present.
● Optics
. LED source:1008x0.2W RGB LED
. Beam angle: 110 °
. Life : 50000H, low power consumption, energy saving and environmental protection
● Colour
. Strobe LED:RGB LED which has uniform and delicate colour mixing effect.
. LEDs control of 112 segments which can bring a more gorgeous chasing effect.
. Color setting
. Super powerful strobe effect
● Specification
. 5 DMX channel modes: 3/ 4/11/29/45 international standard DMX512 channels
. 2 control modes: DMX512, master-slave
. Strobe effect :0-20Hz strobe
. Dimming: 0-100% linear dimming,
● Display
. 4xbutton operation
. Four-digit digital tube display
● Software
. LED refresh rate:3000Hz
● Other functions
. LED temperature detection system to protect the life of the LEDs
. Fan cooling (fan speed based on temperature changing)
● Power / DMX connection
. Power connection: power powerCON power input/ output
. DMX input: 3-pin XLR socket input,output
● Power supply
. AC100-240V 50 / 60HZ
. Power consumption : 250W at full output
● Protection class
. Housing material: full aluminum alloy
. Waterproof level: IP20
● Working environment
. Working temperature: -20 ° C ～ + 40 ° C
● Size and weight
. Packing size: 500x180x300mm
. Net weight: 5.7KG
. Gross weight: 6.1KG
● Certification
. CE ROHS
