Model

GT-KB03

Diameter of wear wheel

150mm

Specimen dimension

ø16.2 mm x thickness 6-10 mm

Specimen moving speed

4.2 mm/r

Weights

Holder 2.5N, can be used arbitrarily with optional accessory 2.5N, 5N (each for one)

Wear wheel speed

40±1rpm

Inclination angle

3°, Test piece support shaft of test piece becomes vertical angle with roller.

Grit size of sandpaper

#60

Roller length

460mm

Wear stroke

40m

Power supply

1∮AC 220V 50/60HZ 3A

Dimensions (L x W x H)

700 x 300 x 300 mm

Weight

55kg

Standards

DIN-53516, JIS-K6369, JIS K6264-2, GB/T 20991 section 8.3, GB/T 20265, GB20266-2006, GB/T 9867, EN ISO 20344 section 8.3, AS/NZS 2210.2 section 8.3, ISO 4649, SATRA TM174, BS903-A9 Method A, ASTM D5963,  ISO20871, QB/T2884, SATRA TM 193, EN 12770

Standard accessories

1pc

2.5N weights

1pc

5N weights

1pc

P60# standard abrasive paper

1pc

Standard cutting die

1pc

Metal blob(Grinding head)

1pc

Power line

Option accessories

Optional

GT-G203H Electronic balance (210g,accuracy 1mg)

Optional

Standard rubber
