Product Name: RS485 Bluetooth USB Finger Scanner for Android Iphone Ipad IOS
Description:
Bluetooth fingerprint scanner FRT1022's fingerprint and intelligent card identification, through wireless communication between Bluetooth and smart phone, can be achieved. The area collector on real skin puts and end to artificial fingerprints, solving the problems of hard fingerprints recognition tasks. Fingerscanner FRT1022 can be applied to various kinds of attendance and consumption system, mobile authentication as oil duct and railway workers inspection, the policeman on duty, etc.
Features:
．Support computer and smart phone system integration
．Eliminate the false fingerprints
．Verify dry, moist fingerprints
．Elegant design and small dimension
．USB charge couple and communication
．Bluetooth wireless communication
．Meet FBI certificate standard
．Modify SDK on basis of clients' requirements
Specifications:
Communication
|
Bluetooth and USB
|
Operating voltage
|
3.7V Li-Ion(1000maH)
|
Operating current
|
Max 100mA
|
Sensor
|
Capacitive Sensor
|
Fingerprint capture
|
Area type fingerprint
|
ESD Sensitivity
|
IEC6100-4-2 15KV
|
RFID
|
Mifare(13.56MHz A type)
|
Operation Temperature
|
-25°C--+70°C
|
Operating Humidity
|
0-95%
|
Size
|
83mm(L) x42.5mm(W) x16.5mm(H)
|
Compatible OS
|
Windows,Linux,Android, IOS
|
Gross Weight
|
0.5KG
|
