SC18IS600IPW NXP Interface ICs
Parameter
| Manufacturer |
NXP Semiconductors |
| Product Category |
I/O Controller Interface IC |
| Mounting Style |
SMD/SMT |
| Package / Case |
TSSOP-16 |
Series
|
SC18IS600
|
Minimum Operating Temperature
|
- 55 C
|
Maximum Operating Temperature
|
+ 125 C
|
Packaging
|
Tube
|
Factory Pack Quantity
|
96 |
Introduction
The SC18IS600IPW offers a simple and efficient way to interface SPI devices with I2C buses, making it ideal for use in a wide range of embedded applications. The chip is designed to operate over a wide temperature range (-40°C to +85°C) and can support data rates up to 3.4 Mbps.
The SC18IS600IPW features a compact 20-pin TSSOP (Thin Shrink Small Outline Package) package and operates using a single supply voltage of 1.8 V to 5.5 V. The chip also incorporates advanced features, such as clock stretching, multi-master capability, and interrupt output, making it well-suited for use in complex embedded systems.
Overall, the SC18IS600IPW is a versatile and reliable SPI to I2C bridge IC that offers excellent performance and flexibility for a wide range of embedded applications.
Application
The SC18IS600IPW is widely used in various industries, including industrial automation, consumer electronics, and Internet of Things (IoT) devices. It is commonly used in applications such as sensor data acquisition and control, display interfaces, and communication interfaces. The SPI-to-I2C bridge IC provides a simple and efficient way to interface SPI devices with I2C buses, making it an ideal component for embedded systems that require seamless communication between different devices and interfaces. Additionally, the compact size, low power consumption, and wide temperature range of the SC18IS600IPW make it well-suited for use in portable and battery-powered devices.
