Security checkpoint hall tent for exhibition
Security checkpoint hall tent ,normally combined with the exhibition tent , like in the canton fairs since 2003 till 2012 ,Tsingtao beer festival ,zhengzhou airshow exhibitions, zhuhai airshow exhibtions 2014,etc. , we can see many security checkpoint hall everywhere ,these tents can do 3m to 60 meters span ,unlimited length ,which can be capacity for thousands of people inside the tent. wherever your security checkpoint is , we can come there for tent service .
The sidewalls are plain PVC fabric to save the cost , also, you can choose glass walls in front of the exhibition tent for beautiful-looking , and at least two double-wing glass door are suggested to install for the tent . The advertisement can be printed on the front gable triangle of the exhibition tent.
according to the size and scale of the tent , the side height of 4m to 6m is optional for the tent , the LED lighting is used every 25 to 35 m2, For the safety of people in the exhibition , the security equipment is installed in this tent , sometimes it should be mobile , then the tents should be mobile too . To protect the security out of the rain and wind , the tent is the standard equipment for the exhibition in the world now.
Security Checkpoint Tent's Cover:
● Kedered roof fabric and sidewalls provide weather-proof tight coverings.
● Bar tensioning roof & sidewalls system.
● Different brand fabric for option: China Fabric, Ferrari, Sioen, Verseidag.
Security Checkpoint Tent's Available size:
● Clear span available between 10-40m.
● Modular structure, the length is adjustable by 5m unit.
Security Checkpoint Tent's Frame:
● No maintenance requirement.
● Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
● All steel connectors including small parts have galvanized finishing above 60um.
The Specification of Security Checkpoint Tent For Exhibition:
Type
|
Span
(m)
|
Side
height (m)
|
Ridge
height (m)
|
Bay
Distance (m)
|
Roof
Pitch
|
Longest
Component (m)
|
Wind
Load (km/h)
|
WS6/3-3
|
6
|
3
|
4.1
|
3
|
20°
|
3.5
|
80
|
WS9/3-3
|
9
|
3
|
4.6
|
3
|
20°
|
4.9
|
80
|
WS10/3-3
|
10
|
3
|
5.1
|
3
|
20°
|
6.5
|
80
|
WS15/3-3
|
15
|
3
|
5.6
|
3
|
20°
|
8.1
|
80
|
Main
frame Profile
|
122x68x3mm(4-channel)
|
Eave
Connection
|
Hot-dip
Galvanized Steel Insert
|
Roof
Fixing
|
Bar
Tension
|
Frame
Material
|
Hard
Pressed Extruded Aluminum 6061/T6
|
Cover
Material
|
Double
PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m
|
