Description
SCT Self-Fusing Silicone Rubber Electrical Tape is made by silicone, it is self-free which is self-fuses when wrapped over itself.
Features
The tape is overlaped by 50% when wraping, which provides the entire assembly with stability. Safety wire, clamps, ties or pure silicone tape can be used to secure the tape in place after installation.
Application
Appliance and Fixture, Automotive and Marine, Commercial Construction, Industrial Construction, Irrigation, Maintenance and Repair Operations, Mining, Solar, Utility, Wind Power
Specifications
|
DATASHEET
|
|
Part number
|
Thickness
|
Width
|
|
mm
|
mm
|
|
SCT-25-0.3
|
0.3
|
25
|
|
SCT-25-0.4
|
0.4
|
25
|
|
SCT-25-0.5
|
0.5
|
25
|
|
SCT-25-1.0
|
1.0
|
25
|
|
SCT-50-0.3
|
0.3
|
50
|
|
SCT-50-0.4
|
0.4
|
50
|
|
SCT-50-0.5
|
0.5
|
50
|
|
SCT-50-1.0
|
1.0
|
50
|
|
Technical Datasheet
|
|
Material
|
Silicone
|
|
Working temperature
|
-40℃ - +260℃
|
|
Flammability
|
VW-1
|
|
Melting point
|
+550℃
|
|
Standard Color
|
Red
|
|
Standard thickness
|
0.3 mm
|
|
MOQ
|
500 meter each size
|
|
Cutting tool
|
Scissors
|
Notes:
The part NO. will be followed by BK for black color, GR for gray color, OR for orange color, BL for blue color. Special color upon request.
Special thickness and width upon request
Special length or packing upon request.
