Set Top Box Pcb Circuit Board Pcba Assembly Supplier
The STREAMTM 4K set-top box supported by Android TV, with the help of Google Assistant, can access entertainment, control smart home devices,
find the latest blockbusters, check contest points, and so on.
|
Specification
|
|
Chipset
|
Amlogic S905X-J
|
|
RAM
|
2GB
|
|
Flash
|
Emmc 8GB
|
|
Video Decoding
|
VP9 Profile-2 up to 4K×2K@60fps
H.265 HEVC MP-10@L5.1 up to 4K×2K@60fps
AVS-P2 Profile up to 4K×2K@60fps
H.264 AVC HP@L5.1 up to 4K×2K@30fps
H.234 MVC up to 1080P@60fps
MPEG-4 ASP@L5/up to 1080P@60fps(ISO-14496)
WMV/VC-1 SP/MP/AP up to 1080P@60fps
AVS-P16（AVS+）/AVS-P2 JiZhun Profile up to 1080P@60fps
MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
RealVideo 8/9/10 up to 1080P@60fps
|
|
Video File Format
|
Support*,mkv*,wmv*,mpg*,mpeg*,dat*,avi*,mov*,iso*.
mp4*,rm*,jig*,bmp*,gif*
|
|
Video Output
|
HDMI 2.1 HDCP2.2
|
|
Aspect Ratio
|
Auto,Full screen
|
|
Video Resolution
|
4K,1080p/i,720p
|
|
Audio Decoding
|
MEPG,AAC,HE-ACC,OGG,OGA,FLAC,ALAC,Ape,M4A,RM,MPEG-1 layer1/2,MPEG-2 layer II，Dolby Digital Plus,Dolby Vison
|
|
DC input Range
|
5V/2.0A
|
|
Power Consumption
|
Maximum 10W
|
Jingchen S905 chip adopts a 64-bit processor with a 28-nanometer process and four cores. Developed based on ARM Cortex-A53, the highest frequency is 2GHz. GPU is equipped with five-core ARM Mali-450. Decoding capabilities support ultra-high-definition 4K@60fps hardware decoding, H.265 10-bit, H.264 and AVS+ and many other formats; encoding capabilities support H.264 1080p 60fps hardware encoding, and output support HDMI 2.0 and CVBS output.
I. Product advantages
1. The volume is small, only 82.0 x 57.5 x 11.5 mm, with a compact mini structure.
2. The USB Type-C slot is used as the power source. TVI is the first OTT box to use the USB Type-C slot.
3. Molex brand is used for TF card slot.
4. RTL8822CS dual-channel SDIO interface, 11AC dual-band BT5.0 Bluetooth WiFi two-in-one module TL8822CSA has become the new favorite in the market, the hardware is compatible with AP6330/AP6356S/QCA6174A and other series of 15*13mm size modules
5. DDR / EMMC use the original premium brand SkHynix / Samsung.
6. OSP (anti-oxidation) four-layer board
7. Strictly follow electrical specifications, SMD with ESD and general rules.
8. Strictly abide by the rules of the HDMI 4K specification and use an independent LDO power module for power supply.
II. About the design of TVI
1. Build 3 types of operating systems, namely Android 6.0, Ubuntu and OpenELEC
2. Added RTC module to realize time memory during power failure and IoT expansion
3. The MCU module is added independently, and the supported startup function realizes the device through IRM and hardware security functions
4. Support alarm boot (you can set the boot time when needed)
5. TVI is scalable
Ultra-fast
PCB assembly, guaranteed top-notch quality and service. Our ODM pcb Board is unlike any low volume manufacturer, offering high quality,
speed and agility.
FAQ:
Q: Are you TV box pcba trading company or manufacturer?
A: We are professional TV box PCB assembly manufacturer. And we trade our products with our clients directly.
Q: Do you provide OEM/ODM?
A: Sure, OEM and ODM are both acceptable. The material, color, style can customize, the basic quantity we will advise after we discuss.
Q: How can I get the TV box PCB assembly quotation?
A: Please send us Gerber files and BOM list. If you don't have this, please tell us your requirements to sale managers.
