Technical data
Capacity
|
105±5bags/min
|
Max.Dosage
|
10 cm³
|
Size of tea bag (L×W)
|
65mm x 62.5mm
|
Size of envelope (L×W)
|
82mm x 75mm
|
Width of filter paper
|
125mm (140mm option)
|
Tag dimensions
|
26mm × 24mm (Heat sealable tag) , 28 mm×24 mm (Glue tag)
|
Thread length
|
220mm
|
Envelope materials
|
Various materials( Plastic / Foil / P.E, Paper / P.E )
|
Voltage
|
AC 380V/220V
|
Total power
|
2.5 KW
|
Overall dimension
|
1688m×1330m×2205m
|
Carton dimensions
|
1840m×1290m×1890m
|
Net Weight
|
1210kg
|
Gross weight
|
1410kg
|
Options
|
1) Heat sealable tag device 2) Date printing device 3) Semi carton device 4) Pneumatic vacuum feeder 5) Modification cutter tool
|
packing materials
1.heat sealing filter paper:single side heat sealing ,at 16.5-20g/m2 and 125mm width
2.tag paper,the tag paper should be bleached paper for food industry,70g/m2
3.cotton thread,the thread should be original cotton thread with 3 standards of NO.16
4 outer bag:works with various heat sealable laminated materials: Plastic/foil/PE,paper/PE,paper/PE,plastic/PE
Packing materials
Heat sealing filter paper : Single side heat-sealing ,16.5-21g/㎡ ,width:125mm .
Various heat sealable laminated materials : Plastic / Foil / P.E, Paper / P.E, Paper / Foil / P.E, Plastic / P.E.
Cotton thread : The thread should be original cotton thread with 3 strands of No.16 (21/4 in English System) thread wound into cone.
Tag paper : The tag paper should be coatched paper for food industry specially.High temperature ink print.
Filter paper: 5750bags/kg
Heat sealable tag paper:6250tags/kg
Cotton thread: 20000teabags/Roll
Envelope paper: 1000 bags/kg
Note : The consumption is collected from untransparent OPP20 / Pearl OPP 35 film.Other materials will be different. Counted according to the number of bags.
