AF11 Shoes Thermal Insulation Tester
Application Of Shoes
Thermal Insulation Tester
Shoes Thermal Insulation tester suitable to doing cold resistance test for all kinds of shoes and boots.
Test Principle of Shoes Thermal Insulation Tester
Filled the sample shoe with steel balls and put a temperature probe in the insole of the shoe, then seal the shoe with a sealing plug, put it in a cryogenic box, observe the temperature changes in sole to determine its cold resistance ability.
Standards Of Shoes Thermal Insulation Tester
ISO 20344, GB/T20991
Key Specification Of Shoes Thermal Insulation Tester
|
Model
|
AF11 Shoes Thermal
Insulation tester
|
|
Temperature range
|
-30～RT, -50～RT
option
|
|
Temperature accuracy
|
±0.1℃
|
|
Temperature uniformity
|
±1 ℃
|
|
Stainess steel ball diameter
|
ø5 mm
|
|
Window
|
210×35×270
mm, two lattice vacuum
|
|
Window lights
|
P1 light, 5 W
|
|
Inter size
|
600×600×550 mm
|
|
Power supply
|
AC220V, 50/60HZ
|
|
Dimension
|
2000×780×1000
mm
|
|
Weight
|
280 kg
|
