Product Description:
Several function blocks are available at the station level for the configuration of STATION level parameters, such as the station address and station tag name. Function blocks include the CLOCK block (when the RTC/CB option board has been included), and the ETHERNET block (when the Ethernet board has been installed and the controller contains firmware V2.4 or higher) to configure parameters such as the IP address. All other function blocks are used for configuration within an individual LOOP. Control implementations are configured in the Moore 353 by first creating a loop, then entering a unique loop tag name, and selecting function blocks for use within that loop. A number of loops can be configured in the Moore 353 and a number of function block types are available as described in the sections that follow.
Local I/O Function Blocks are provided on both the MPU Controller Board and the I/O Expander Board. These blocks can be used in any LOOP, but as fixed resources are expendable. When used within a loop, the unique block name becomes.
