Specifications
| Primary brand |
Siemens |
| Main function |
Soft starter |
| Product series / family name |
SIRIUS 3RW30 series |
| Network frequency |
(input) 50-60 Hz |
| Functions |
Basic performance soft-starter
Soft starting/ramp-down
Voltage ramp
1 parameter sets
2 controlled phases |
| Design |
integrated bypass |
| Supply voltage (AC) |
200Vac-480Vac (208Vac / 240Vac / 400Vac) |
| Type of network |
3-phase (3P / 3AC) |
| Rated current |
38A (operational current at 40°C)
34A (operational current; 50°C) |
| Rated active power (kW) |
11kW (at 230Vac at 40°C)
18.5kW (at 400Vac at 40°C) |
| Rated power (HP) |
10HP (200Vac; 50°C)
10HP (230Vac; 50°C)
25HP (460Vac; 50°C) |
| Rated operating voltage (Ue) |
200-480 V |
| Connection type |
Screw connection |
| Control Voltage (AC) |
24Vac |
| Control Voltage (DC) |
24Vdc |
| Mounting mode |
Wall |
| Degree of protection |
IP20 |
| Dimensions |
Frame size S0
W45mm x H125mm x D151mm |
| Ambient air temperature for operation |
-25...+60 °C |
| Ambient air temperature for storage |
-40...+80 °C |
| Power dissipation/losses |
(in operation after completed starting with uninterrupted rated operational current 40°C approx.) 19 W
(during starting with 300% IM 40°C) 256 W |
| Application type |
Pumps
Heat pumps |
| Compliant with standard(s) |
IEC 60721
IEC 60947-4-2 |
| Class |
Class 10 |
