Specifications
| Primary brand |
Siemens |
| Main function |
Power supply unit |
| Product series / family name |
SITOP Smart series |
| Sub-range name |
PSU100S |
| Functions |
Regulated AC/DC power supply unit (SMPS PSU) |
| Supply voltage (AC) |
85-132Vac / 170-264Vac (120Vac / 220Vac / 230Vac / 240Vac nom.) (47...63Hz) |
| Display |
Green LED (DC output OK) |
| Type of network |
Single-phase (1AC)
2-phase (2AC) |
| Rated current |
10A
32A / 1000ms max. boost
15A (5s every minute) |
| Rated power |
240W |
| Output voltage (DC) |
22.8-28Vdc (24Vdc nom.) |
| Hold time |
20ms (93/187Vac input) |
| Connection type |
Screw-clamp term. connections |
| Protection functions |
Output overvoltage protection (<33V)
6.3A built-in incoming fuse (not accessible)
Overshoot of Vout < 3%
Electronic short-circuit protection (constant current) |
| Efficiency |
90% |
| Mounting mode |
DIN rail (35x7.5 / 35x15) |
| Time delay |
300ms start-up time |
| Digital outputs |
1 x digital output (NO Normally Open contact) (DC output OK remote signalling) |
| Degree of protection |
IP20 |
| Dimensions |
W70mm x H125mm x D120mm |
| Net Width (mm) |
70 mm |
| Ambient air temperature for operation |
-25...+70 °C |
| Ambient air temperature for storage |
-40...+85 °C |
| Equivalent to |
SITOP PSU100S/1AC/24VDC/10A
6EP13342BA20 |
| Compliant with standard(s) |
CE marking
cULus-Listed (UL 508; CSA C22.2 No. 107.1); file E197259
cCSAus (CSA C22.2 No. 60950-1; UL 60950-1)
BV
DNV GL (Germanischer Lloyd's)
EN 55022 Class B (Emitted interference)
EN 61000-3-2 (Supply harmonics limitation)
EN 61000-6-2 (Noise immunity) |
| Benefits |
SITOP smart are the universal and powerful standard power supplies for mechanical and plant engineering.
Despite their compact design they offer excellent overload behavior. Thanks to a power boost of 150% loads with high power consumption can be connected without any problems and the permanent overload capability of 120% offers power reserves in case of expansions.
The high degree of efficiency results in low energy consumption and minimal heat generation inside the control cabinet.
To further increase 24V availability; the SITOP smart power supplies can be combined with buffer; DC-UPS; redundancy and selectivity modules
Single-phase and three-phase standard applications up to 40A
Compact design; no lateral clearances required
Extra power with 1.5 times the rated current (5 s/min) for brief operational overloads
Permanent overload capability with 1.2 times the rated current up to 45 °C ambient temperature
Adjustable output voltage for compensating voltage drops
Parallel switching option to increase performance
High degree of efficiency up to 91.5%
Wide temperature range from -25 °C or 0 °C to +70 °C
Comprehensive certification such as cULus; cCSAus; ATEX; IECEx and GL |
| Ripple |
150mVpp max.
20mVpp typ. |
| MTBF (Mean Time Between Failures) |
1 614 510 hours |
