Product Details:
- Input
- Voedingsspanning/1/bij AC: 120... 230 V
- Supply voltage/2/with AC: 230... 500 V
- Input voltage/1/at AC: 85... 264 V
- Input voltage/2/at AC: 176... 550 V
- Wide range input: Ja
- Mains buffering at Iout rated, min.: 25 ms
- Netfrequency: 50/60 Hz
- Rated line range: 47 63 Hz
- Input current/at nominal level of the input voltage: 120 V 4,4 A
- Ingangstroom/bij nominale waarde van de ingangsspanning: 230 V 2,4 A
- Input current/at nominal level of the input voltage: 500 V 1,1 A
- Switch on current limit (+25 ° C), max: 35 A
- I2t waarde: 4 A ²· S
- Output
- Curvevorm van de spanning Geregelde, potentialvrije gelijkspanning
- Uitgangspan: 24 V
- Total tolerance, static: ± 3%
- Static mains compensation, approval.: 0,1%
- Static load balancing, approval.: 0,1%
- Residual ripple peak peak, max: 50 mV
- Spikes peak peak peak, maximum. (bandwidth: 20 MHz): 200 mV
- Adjustment range: 24... 28,8 V
- Product feature/output voltage adjustable: Ja
- Uitvoering van de energave LED groen voor: 24 V O.K
- Aanspreekvertragingstijd: 1 s
- Spanningsstijgingstijd: 50 ms
- Rated current value Iout rated: 10 A
- Uitgangstroom: 0... 10 A
- Delivered active power/typ.: 240 W
- Constant overload current/in the event of a short circuit during startup/typical: 12 A
- Short term overload current/at short circuit during operation/typical 30 A
- Duration of overload ability for excess current/on short circuiting during the operational phase: 25 m
- Producteigenschap: Ja
- Numbers of parallel switchable units for enhanced performance: 2
