Specifications
| Primary brand |
Siemens |
| Main function |
CPU unit |
| Product series / family name |
SIMATIC |
| Functions |
Programmable Logic Controller (PLC) CPU processor module
Hardware clock
PID controller
Motion control with 800 resources for technology objects (except cam disks)
PG/OP communication
S7 routing
SIMATIC communication
Open IE communication
Web server
Media redundancy (MRP Client)
User program protection / password protection
Copy protection
Block protection
OPC UA Server (Data Access) |
| Design |
display |
| Supply voltage (DC) |
24Vdc |
| Display |
3.45cm Plain text display |
| Programming languages |
STEP 7
LAD (Ladder)
FBD (Function Block Diagram)
STL (Structured Text)
SCL (Structured Control Language)
GRAPH |
| Memory capacity |
32GBytes (ROM)
150kB (RAM for program)
1MB (RAM for data)
2048B (Timers)
2048B (Counters)
16kB (Flags)
32kB (Process image) |
| Connection capacity |
96 x communication connections
128 x PROFINET IO devices |
| Connection type |
RJ45 connectors x 2 |
| Communication protocol |
PROFINET
PROFINET IO |
| Mounting mode |
Backplane / rack |
| Operating mode |
Isochronous mode |
| Degree of protection |
IP20 |
| Net Height (mm) |
147 mm |
| Net Width (mm) |
35 mm |
| Net Depth (mm) |
129 mm |
| Ambient air temperature for operation |
0...+60 °C |
| Processing time |
60ns (bit operation) - 0.00006 ms
72ns (word operation) - 0.000072 ms
96ns (fixed point arithmetic) - 0.000096 ms
384ns (floating point arithmetic) - 0.000384 ms |
| Power dissipation/losses |
5.7 W |
| Equivalent to |
6ES75111AK020AB0 |
| Replaces |
6ES7511-1AK01-0AB0 |
| EAN code |
4047623409137 |
| UPC code |
804766671722 |
| Compliant with standard(s) |
CE
cULus
FM
RCM
KCC
cULus HazLoc
ATEX
IECEx
IEC61131
IEC61000-6-2
IEC61000-4-3
IEC61000-4-4
IEC61000-4-5
IEC61000-4-6
IEC60068-2-6
IEC60068-2-27
IEC61000-6-4
EN60068-2-1
EN60068-2-2
EN60068-2-6
EN60068-2-14
EN60068-2-27
EN60068-2-30
EN60068-2-32 |
| Storage type |
SIMATIC memory card |
| Application type |
Medium requirement for program scope and processing speed
Central controller in production lines with central and distributed I/O |
