Specifications
| Primary brand |
Siemens |
| Main function |
Safety CPU unit |
| Product series / family name |
SIMATIC |
| Sub-range name |
S7-1500 |
| Functions |
Fail-safe / Safety Programmable Logic Controller (PLC) CPU processor module
Hardware clock
PID controller
Motion control with 10240 resources for technology objects (except cam disks)
PG/OP communication
S7 routing
SIMATIC communication
Open IE communication
Web server
Media redundancy (MRP Client)
User program protection / password protection
Copy protection
Block protection
OPC UA Server (Data Access)
IRT interface |
| Design |
display |
| Supply voltage (DC) |
24Vdc |
| Display |
6.1cm Plain text display |
| Programming languages |
STEP 7
LAD (Ladder)
FBD (Function Block Diagram)
STL (Structured Text)
SCL (Structured Control Language)
GRAPH |
| Memory capacity |
32GBytes (ROM)
3MB (RAM for program)
8MB (RAM for data)
2048B (Timers)
2048B (Counters)
16kB (Flags)
32kB (Process image) |
| Connection capacity |
320 x communication connections
125 x DP slaves
512 x PROFINET IO devices
128 x PROFINET IO devices |
| Connection type |
RJ45 connectors x 3
D-Sub connector |
| Communication protocol |
PROFINET
PROFINET IO
PROFIBUS DP
PROFIsafe
RS-485 |
| Mounting mode |
Backplane / rack |
| Operating mode |
Isochronous mode |
| Degree of protection |
IP20 |
| Net Height (mm) |
147 mm |
| Net Width (mm) |
175 mm |
| Net Depth (mm) |
129 mm |
| Ambient air temperature for operation |
0...+60 °C |
| Processing time |
2ns (bit operation) - 0.000002 ms
3ns (word operation) - 0.000003 ms
3ns (fixed point arithmetic) - 0.000003 ms
12ns (floating point arithmetic) - 0.000012 ms |
| Power dissipation/losses |
24 W |
| Equivalent to |
6ES75173UP000AB0 |
| EAN code |
4047623406525 |
| UPC code |
804766333934 |
| Compliant with standard(s) |
CE
cULus
FM
RCM
KCC
cULus HazLoc
ATEX
IECEx
IEC61131
IEC61000-6-2
IEC61000-4-3
IEC61000-4-4
IEC61000-4-5
IEC61000-4-6
IEC60068-2-6
IEC60068-2-27
IEC61000-6-4
EN60068-2-1
EN60068-2-2
EN60068-2-6
EN60068-2-14
EN60068-2-27
EN60068-2-30
EN60068-2-32 |
| Class |
PLe
SIL3 |
| Storage type |
SIMATIC memory card |
| Application type |
High processing speed for binary and floating-point arithmetic
Central controller in production lines with central and distributed I/O
Cross-industry automation tasks in series machine; special machine; plant construction |
