Technical specifications
|
Processor
|
Integrated CPU for mid-range applications
|
|
Work Memory
|
128 KB (program), 256 KB (data)
|
|
Load Memory
|
Expandable via MMC card (up to 8 MB)
|
|
Digital Inputs
|
16 (24V DC)
|
|
Digital Outputs
|
16 (24V DC)
|
|
Analog Inputs
|
4 (0-10V, 4-20mA, 12-bit resolution)
|
|
Analog Outputs
|
2 (0-10V, 4-20mA, 12-bit resolution)
|
|
I/O Address Range
|
2048 bytes (input/output)
|
|
PROFIBUS DP Port
|
1 x DP master/slave interface, up to 12 Mbps
|
|
MPI Interface
|
Supported
|
|
Power Consumption
|
3.5 W (typical)
|
|
Humidity
|
5% to 95% non-condensing
|
|
Protection Rating
|
IP20
|
|
Dimensions (H x W x D)
|
125 x 50 x 130 mm
|
|
Weight
|
0.6 kg (1.32 lbs)
|
|
Certifications
|
CE, UL, CSA
|
|
EMC Compliance
|
IEC 61000-6-2, IEC 61000-6-4
|
FAQ:
1. Are there any built-in safety features?
The module includes short-circuit protection for each output channel, helping to prevent damage in the event of an overload.
2. What is the operating temperature range for the module?
The typical operating temperature range is between 0°C and 60°C (32°F to 140°F). Refer to the product manual for more detailed specifications.
3. Where can I find additional documentation?
Additional documentation, including user manuals, installation guides, and technical specifications, can be found on the Siemens official website or through authorized distributors.
