Specifications
| Primary brand |
Siemens |
| Main function |
Variable Speed/Frequency Drive (VSD/VFD) / Inverter |
| Product series / family name |
SINAMICS S120 series |
| Sub-range name |
PM240-2 |
| Network frequency |
(input) 47-63 Hz |
| Functions |
Pwr. module |
| Design |
brk. chopper |
| Supply voltage (AC) |
380Vac-480Vac (400Vac / 415Vac / 440Vac) |
| Frequency |
(output; V/f control mode) 0-550
(output; vector control mode) 0-240 |
| Type of network |
3-phase (3P / 3AC) |
| Rated current |
3.1A (low overload LO)
2.2A (based-load current IH for high overload HO) |
| Rated active power (kW) |
1.1kW (low overload LO)
0.75kW (high overload HO) |
| Rated power (HP) |
1.5HP / 1-1/2HP (low overload LO)
1HP (high overload HO) |
| Connection type |
Term. connector (line supply / motor connection)
Term. connector (PE connection） |
| Protection functions |
Undervoltage
Overvoltage
Overload
Ground fault
Short-circuit
Stall protection
Motor blocking protection
Motor over-temperature
Inverter over-temperature
Parameter locking |
| Efficiency |
0.96 |
| Degree of protection |
IP20 |
| Dimensions |
Frame size FSA
W73mm x H196mm x D165mm |
| Ambient air temperature for operation |
(low overload; without derating) -10...+40 °C
(high overload; without derating) -10...+50 °C |
| Mechanical resistance |
Vibration resistance
Shock resistance |
| Power dissipation/losses |
0.04kW / 40 W |
| Order code / Manufacturer SKU |
6SL32101PE132UL1 |
| EAN code |
4042948665954 |
| UPC code |
887621774240 |
| Compliant with standard(s) |
EN 60721-3-1
EN 60721-3-2
EN 60721-3-3
EN 60068-2-6
EN 61800-5-1
CE
cULus
RCM
SEMI F47
RoHS
EAC
WEEE
EN 60204 |
