Siemens 6SL3220-3YE26-0UF0 Power Module

Siemens 6SL3220-3YE26-0UF0  Power Module

Siemens 6SL3220-3YE26-0UF0 Power Module is an advanced power electronics solution from the Siemens SINAMICS S120 series.

Designed for medium to high-performance applications, this power module ensures efficient motor control and precise motion sequences.

Ideal for industrial automation environments, the module provides reliable power conversion and control for servo, main, and induction motors.

If you want to know more about 6AV6643-0DD01-1AX1 , please contact me

    Email                                        Skype                                    Wechat                                 Whatsapp

 sales17@amikon.cn              +86 189 65196563                   Amikonplc                          +86 189 65196563

Technical specifications

Series: SINAMICS S120
Model Number: 6SL3220-3YE26-0UF0
Power Type: Power Module
Input Voltage: 3-phase, 380-480V AC
Output Power: 240 kW
Frequency Range: 0-550 Hz
Rated Output Current: 480 A
Efficiency: > 96%
Cooling Method: Air cooling
Mounting Type: Cabinet mount
Dimensions (HxWxD): 538 mm x 274 mm x 300 mm
Weight: 5 kg
Communication Interface: PROFINET, PROFIBUS
Protection Class: IP20
Operating Temperature Range: -10°C to +40°C
Overload Capability: 150% for 60 seconds
Standards Compliance: IEC 61800-5-1, CE, UL, RoHS
