GTL power system offer custom-built power generation system. By first examining our customers' needs and circumstances before proposing the best arrangement. Our customers can select the most appropriate power generation system from a wide variety of equipment and specifications. We provide comprehensive support from the design stage to after-sale service, satisfying customers across the globe with high-quality products and services.
|
Model
|
1800 rmp/480v 3P 4W/60HZ/0.8PF
|
Engine Type
|
Dimensions(LxWxH)&Weight
|
DOWNLOAD
|
|
Prime Power
|
Standby Power
|
Open Genset
|
Silent Genset
|
|
KVA
|
KW
|
KVA
|
KW
|
Dimension(mm)
|
weight(kg)
|
Dimension(mm)
|
weight(kg)
|
|
MSW-875T6
|
875
|
700
|
963
|
770
|
S12A2-PTA
|
4100*1725*2080
|
7429
|
6058*2438*2591
|
11429
|
|
|
MSW-1050T6
|
1050
|
840
|
1155
|
924
|
S12H-PTA
|
4500*1775*2400
|
9190
|
6058*2438*2591
|
13190
|
|
|
MSW-1155T6
|
1155
|
924
|
1271
|
1016
|
S12H-PTA
|
4500*1775*2400
|
9190
|
6058*2438*2591
|
13190
|
|
|
MSW-1375T6
|
1375
|
1100
|
1513
|
1210
|
S12R-PTA
|
4450*2050*2335
|
11507
|
12192*2438*2896
|
19507
|
|
|
MSW-1500T6
|
1500
|
1200
|
1650
|
1320
|
S12R-PTA2
|
4450*2050*2335
|
11787
|
12192*2438*2896
|
19787
|
|
|
MSW-1650T6
|
1650
|
1320
|
1815
|
1452
|
S12R-PTAA2
|
5300*2100*2600
|
12219
|
12192*2438*2896
|
20219
|
|
|
MSW-1850T6
|
1850
|
1480
|
2035
|
1628
|
S16R-PTA
|
5260*2100*2425
|
15200
|
12192*2438*2896
|
23200
|
|
|
MSW-2063T6
|
2063
|
1650
|
2269
|
1815
|
S16R-PTA2
|
5275*2100*2875
|
15123
|
12192*2438*2896
|
23123
|
|
|
MSW-2275T6
|
2275
|
1820
|
2503
|
2002
|
S16R-PTAA2
|
6100*2200*2875
|
16128
|
12192*2438*2896
|
24128
|
|
After-sales service
Installation instructions
After the customer receives the goods, GTL can provide online real-time installation and debugging consultation and guidance, or provide the following services if necessary:
1. Assign engineering and technical personnel with installation experience to the site for installation guidance.
2. Assign skilled technicians with debugging experience to the site to carry out equipment debugging and trial operation together with the engineering and technical personnel of the customer, and submit the test data report.
Training
If customers have needs, our company will arrange technical personnel for training and guidance. Our company can provide factory training, video online training and on-site training for users to choose.
Maintenance services
No matter where your crew is, you can get our professional technical advice and services. GTL will set up customer files for each customer and provide regular inspection service. It can also make maintenance plans for customers and provide corresponding spare parts.
Part of the Case
