Description
Silicone resin non-stick coating S-201 is particularly designed for aluminum, steel and other metal mold coatings. It has outstanding stain resistance, non-stick performance and superior abrasion resistance. It has good heat resistant and workable at 300℃.
Type
Solvent based silicone resin
Key features
-PFOA free
-Excellent heat resistant
-Excellent chemical resistance and abrasive resistance
-Excellent and lasting non-stick performance, easy to clean
Typical properties
Appearance: Yellowish clear liquid
Solid content (%): 35±1
Viscosity (cp): 400~800
Density (g/ml): 1.10
pH: 8-10
Color of the film surface: Flat and smooth
Curing temperature (℃): 280-300
Gloss (60° glossimeter): 15-25
Film thickness (μm): 15-20
Corrosion resistance: No blister (Boling 3% HAc for 1 hours)
Abrasion resistance 3KG/21cm2: >20000 cycles
Hardness (ZHONGHUA pencil): 4H-5H
Application
-Aluminum, steel and other metal mold coating
Storage and handling
-Available in 20 kg/ barrel or 30 kg/ barrel
-Store products in tightly closed original containers at 5-40℃
-Shelf life: 9 months from delivery date
-According to non-dangerous goods transport
Non-stick Coating Type
↓ ↓ ↓ Please click product model for more informations
|
Model
|
Layer
|
Thickness
|
Curing temperature
|
Non stick property
|
Anti-corrosion
|
Abrasion resistant
|
|
Water based fluororesin non-stick coating
|
|
PF-600
|
2
|
25-40
|
380-400
|
A A A A A
|
A A A A
|
A A A
|
|
PF-601
|
2
|
25-35
|
380-400
|
A A A A
|
A A A A
|
A A A
|
|
PF-602
|
2
|
25-40
|
380-400
|
A A A A A
|
A A A A
|
A A A
|
|
PF-610
|
3
|
20-35
|
380-420
|
A A A A A
|
A A A A A
|
A A A
|
|
PF-611
|
3
|
20-35
|
380-420
|
A A A A A
|
A A A A A
|
A A A
|
|
PF-612
|
3
|
20-35
|
380-420
|
A A A A A
|
A A A A A
|
A A A
|
|
Water based ceramic non-stick coating
|
|
C-104
|
1
|
30-45
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-105
|
1
|
30-45
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-106
|
2
|
34-50
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-107
|
1
|
12-20
|
250-280
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-108
|
2
|
34-50
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-109
|
2
|
34-50
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
Silicone resin non-stick coating
|
|
S-200
|
1
|
15-20
|
280-300
|
A A A A
|
A A A A A
|
A A A A
|
|
S-201
|
1
|
15-20
|
280-300
|
A A A A
|
A A A A A
|
A A A A A
|
|
S-202
|
1
|
15-20
|
280-300
|
A A A A
|
A A A A A
|
A A A A
|
