Simulate high altitude low-pressure chamber for lithium battery pouch cell safety performance testing
SPECIFICATIONS
|
Type
|
TOB-BE-DY-27
|
TOB-BE-DY-64
|
TOB-BE-DY-125
|
TOB-BE-DY-216
|
TOB-BE-DY-512
|
|
Box size within
|
W300*D300
*H300mm
|
W400*D400
*H400mm
|
W500*D500
*H500mm
|
W600*D600
*H600mm
|
W800*D800
*H800mm
|
|
Box size outside
|
W600*D470
*H710
|
W700*D570
*H810
|
W800*D670
*H910
|
W900*D870
*H1010
|
W1100*D1070
*H1210
|
|
Weight
|
90kg
|
110kg
|
130kg
|
150kg
|
200kg
|
|
Box material in
|
Stainless steel thickness:6.0mm
|
|
Box material outside
|
SECC Steel sheet，Fine powder coating process, Thickness：1.5mm
|
|
Timer
|
Three display 999(H:hour,M:minute,S:Second Switchable)
|
|
Power supply
|
AC 220V 50HZ
|
|
Power
|
0.2KW
|
|
Vacuum pump
|
Standard configuration
|
