Description
Single layer black ceramic non-stick coating C-105 is single layer ceramic coating, smooth hand feeling, excellent heat resistance, excellent non-stick performance and abrasion resistant It can be used on non-stick cookware and household appliance.
Type
Ceramic nano material
Key features
-PFOA free
-Excellent heat resistant (>400℃)
-Excellent non-stick performance and easy to clean
-Superior chemical resistance and abrasive resistance
Typical properties
Appearance: Black
Solid content (%): 52±1
Viscosity (cp): 600~1000
Density (g/ml): 1.20
Color of the film surface: Black
Curing temperature (℃): 280-300
Gloss (60° glossimeter): >35
Film thickness (μm): 30-45
Non-stick performance: >10 cycles (Fry eggs at 170±10℃)
Corrosion resistance: No blister (Boling 10% salt water for 24 hours)
Abrasion resistance 3KG/21cm2: >8000 cycles
Hardness (ZHONGHUA pencil): >6H
Application
-Aluminum and stainless steel fry pan, wok, soup pot, rice cooker, electric pressure cooker, electric saucepan, electric baking tray, cake mould etc.
Storage and Handling
Available in 20 kg/ barrel or 30 kg/ barrel
Store products in tightly closed original containers at 5-40℃
Shelf life: 9 months from delivery date
According to non-dangerous goods transport
Non-stick Coating Type
↓ ↓ ↓ Please click product model for more informations
|
Model
|
Layer
|
Thickness
|
Curing temperature
|
Non stick property
|
Anti-corrosion
|
Abrasion resistant
|
|
Water based fluororesin non-stick coating
|
|
PF-600
|
2
|
25-40
|
380-400
|
A A A A A
|
A A A A
|
A A A
|
|
PF-601
|
2
|
25-35
|
380-400
|
A A A A
|
A A A A
|
A A A
|
|
PF-602
|
2
|
25-40
|
380-400
|
A A A A A
|
A A A A
|
A A A
|
|
PF-610
|
3
|
20-35
|
380-420
|
A A A A A
|
A A A A A
|
A A A
|
|
PF-611
|
3
|
20-35
|
380-420
|
A A A A A
|
A A A A A
|
A A A
|
|
PF-612
|
3
|
20-35
|
380-420
|
A A A A A
|
A A A A A
|
A A A
|
|
Water based ceramic non-stick coating
|
|
C-104
|
1
|
30-45
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-105
|
1
|
30-45
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-106
|
2
|
34-50
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-107
|
1
|
12-20
|
250-280
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-108
|
2
|
34-50
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
C-109
|
2
|
34-50
|
280-300
|
A A A A A
|
A A A A
|
A A A A A
|
|
Silicone resin non-stick coating
|
|
S-200
|
1
|
15-20
|
280-300
|
A A A A
|
A A A A A
|
A A A A
|
|
S-201
|
1
|
15-20
|
280-300
|
A A A A
|
A A A A A
|
A A A A A
|
|
S-202
|
1
|
15-20
|
280-300
|
A A A A
|
A A A A A
|
A A A A
|
