SL-39-APP-K9 AppX License with; DATA and WAAS for Cisco ISR 3900 Series

Cisco Application Experience License ISR 3900 Series - includes licenses for: AppX, DATA and WAASX. Cisco Application Experience License includes the key IWAN components with no additional hardware needed for features, including DATA license features, Dynamic Multipoint VPN (DMVPN), Cisco Performance Routing Version 3 (PfRv3), AVC, Network Based Application Recognition 2 (NBAR2), quality of service (QoS), etc. For WAAS Express a DRAM upgrade is required. All WAAS licensing is included with the APP license, so inclusion of the required hardware is all that is necessary. Note: The APP license does not include a SEC license.

For multiple WAAS instances WCCP for 2900/3900 series is needed to manage multiple node groups using UCS-E or SRE. It is recommended that all WAAS nodes in a WCCP node group have similar capacity/connection limits. So for example with 3900 series which includes 2500 TCP Connections, add one or two UCS-E modules each with vWAAS 2500 for up to 7500 total TCP connections on the router or a single 6k vWAAS instance per UCS-E module up to 8500 total TCP connections. Additional WAAS RTU license is required Multiple vWAAS instances on UCS-E modules is supported up to the max throughput of the router with services enabled.

SL-39-APP-K9 Specification
