SN74LVC1G3157DCKR TI Analog Switch ICs
Parameter
| Manufacturer |
Texas Instruments |
| Product Category |
Analog Switch ICs |
| Mounting Style |
SMD/SMT |
| Package / Case |
SC70-6 |
| Number of Channels |
1 Channel |
Series
|
SN74LVC1G3157
|
Supply Voltage - Min
|
1.65 V
|
Supply Voltage - Max
|
5.5 V |
Minimum Operating Temperature
|
- 40 C
|
Maximum Operating Temperature
|
+ 125 C
|
Packaging
|
Reel/Cut Tape
|
Factory Pack Quantity
|
3000 |
Introduction
The SN74LVC1G3157DCKR is a single-channel analog switch designed for 1.65-V to 5.5-V VCC operation. This device can handle both digital and analog signals and features low on-state resistance and excellent on/off performance. The switch is bidirectional and can pass signals with a wide dynamic range, making it ideal for use in a variety of applications, including audio and video signal switching, signal isolation, and signal multiplexing.
The SN74LVC1G3157DCKR is available in a small 5-pin SC-70 package, making it ideal for space-constrained applications. The device also features a low quiescent current of 0.5 µA, making it suitable for battery-powered applications.
Overall, the SN74LVC1G3157DCKR is a versatile and reliable analog switch that provides excellent performance in a small and low-power package.
Application
The SN74LVC1G3157DCKR is widely used in a variety of commercial applications. It can be used in audio and video signal switching, signal isolation, and signal multiplexing in consumer electronics products such as smartphones, tablets, and laptops. The device's low on-state resistance and excellent on/off performance make it ideal for use in high-speed data transmission applications, such as USB and HDMI interfaces. Additionally, the small size, low power consumption, and bidirectional signal capability of the SN74LVC1G3157DCKR make it a good choice for portable and battery-powered devices. Overall, the SN74LVC1G3157DCKR is a versatile and reliable analog switch that provides excellent performance in a wide range of commercial applications.
