SN74LVC3G17DCTR TI Buffers & Line Drivers
Parameter
| Manufacturer |
Texas Instruments |
| Product Category |
Buffers & Line Drivers |
| Mounting Style |
SMD/SMT |
| Package / Case |
SM-8 |
| Supply Voltage - Min |
1.65 V |
Supply Voltage - Max
|
5.5 V |
| Series |
SN74LVC3G17 |
Minimum Operating Temperature
|
-40 C
|
Maximum Operating Temperature
|
+ 125 C
|
Packaging
|
Reel / Cut Tape
|
Factory Pack Quantity
|
3000 |
Introduction
The SN74LVC3G17DCTR is a chip manufactured by Texas Instruments. It is a triple Schmitt-trigger buffer designed for voltage level translation and signal conditioning applications.
The SN74LVC3G17DCTR chip features three independent Schmitt-trigger buffers, which provide hysteresis to improve noise immunity and signal integrity. It operates at a wide voltage range, making it compatible with both 3.3V and 5V systems.
This chip is commonly used in applications such as data communication interfaces, signal amplification, and voltage level shifting. It can be employed to convert signals between different logic levels, ensuring compatibility between devices operating at different voltage levels.
The SN74LVC3G17DCTR offers high-speed operation with a propagation delay of a few nanoseconds, making it suitable for applications that require fast signal processing. It has a low power consumption, making it an energy-efficient choice for portable and battery-operated devices.
Application
The SN74LVC3G17DCTR chip finds industry applications in voltage level translation and signal conditioning. It is commonly used in data communication interfaces, signal amplification, and voltage level shifting. With its triple Schmitt-trigger buffers, it provides hysteresis for improved noise immunity and signal integrity. The chip operates at a wide voltage range, making it compatible with diverse systems. Its high-speed operation and low power consumption make it suitable for applications that require fast signal processing and energy efficiency. The small SOT-23 package enables compact designs, making it ideal for space-constrained applications. The SN74LVC3G17DCTR is a versatile solution for industries requiring reliable signal conditioning and voltage level translation, ensuring seamless compatibility and efficient signal processing.
