Solar cables POW-CAB-H1Z2Z2-K

The POW-CAB-H1Z2Z2-K cable, which is TÜV certified according to IEC 62930 and EN 50618, is suitable for both fixed and mobile solar installations .



Solar Cables POW-CAB-H1Z2Z2-K



Product Description:

POW-CAB-H1Z2Z2-K is a highly flexible solar cable compatible with all major connectors and specially designed for the connection of photovoltaic panels. This versatile single-conductor cable is designed to meet the varying needs of the solar industry.



solar cables

Product Category:

solar cables



Product Code:

POW-CAB-H1Z2Z2-K



Product Detail:

Nominal voltage1,5kV DC and 1,0kV AC

Maximum permitted operating voltage1,8kV DC(2,0 kV DC internal examination)

Minimum bending radius10x cable diameter(flexible) /4x cable diameter(fixed)

Range of temperature:Ambient temperature -40to +90;Maximum Conductor temperature +120℃;

Standards-Compliantinsulation resistance, UV stability, Resistance against acid and alkaline,

flame retardant, Halogen-free. These have been tested.

Conductor ConstructionTinned copper, according to the VDE 0295/ IEC 60228,Class5

Insulation: Polyolefin copolymer electron-beam cross-linked

Outer Sheath:Polyolefin copolymer electron-beam cross-linked

Application:Suitable for solar power equipment connector to inverter connection, outdoor installation

in different climatic conditions and adaptable to dry and wet indoor working environment.

Certificate:TUV EN50618,TUV IEC 62930

Outer sheath:Low smoke halogen Free rubber, red or black color

PackagingAvailable in rolls (lengths of 100 m) and reels.

Other:Meter by meter marking.
