Roof Solar Panel Mounting Structure System for Metal Roof.
TIN ROOF TILE ROOF
SPECIFICATIONS
▶ Installation site Pitched roof.
▶ Installation angle parallel to the roof.
▶Wind speed <60m/s.
▶Snow load <1.2KN/m2.
▶Build height <20m.
▶Material AI 6063-T5 & SUS304.
▶Surface treatment Anodizing.
▶Refer to standard GB50009,JIS C8955,DIN 1055.
▶Warranty 10-year warranty , 20-year service life.
▶ Pitched roof mounting structure system designs with great flexibility both for commercial and residential roof solar system.
▶ It is suitable for installing framed and frameless modules flushed to the roof .
▶ Easy to install , high preassembly parts and customized solution will save your installation time and money.
▶ Bluesun Solar has developed several special Solar Panel Fixing Systems , by them,Solar Panel Tilt Frames will plying-up roofing and prevent roof leaking.
▶ Solar Panel Fitting Kit with aluminium alloy and stainless steel material will make all Solar Panel Support Structure stable and anti-corrosion.
SOLAR MOUNTING HARDWARES
PACKING
TO HELP YOU GET THE RIGHT SYSTEM,PLEASE KINDLY OFFER THE FOLLOWING NECESSARY INFO:
1. Dimension of solar panels(length*width*thickness)?
2. Quantity of solar panels?
3. Where to install : rooftop (flat roof or pitched roof ) or ground ?
4. Tilt angle?
5. Any requirements about wind load and snow load?
6. Any minimum height requirement(distance from ground to panel)?
