Key Properties:
-
Inherit the simple structure of the traditional C cores
-
Clamp-on core design, safer, easier installation, portable, don’t need to cut of the grid-power when adjust the inductance.
-
Comparing other materials, with high accuracy, due to nanocrystalline high permeability.
-
Energy conservation & environment protection, huge potential market.
|
Typical Specification
|
|
Working Frequency
|
50 ~ 2000 Hz
|
|
Rated Input
|
5 ~ 630 A
|
|
Testing Range
|
10% In ~ 130% In
|
|
Rated Output
|
0.333V(AC); 0~500 mA
|
|
Ratio Turns Error
|
≤± 1.0%
|
|
Phase Error
|
≤±60
|
|
Dielectric Strength
|
2.5KV; 1mA; 1min
|
|
Insulation Resistance
|
DC500V; 100 MΩ min
|
|
Case Material
|
PA (UL flame retardant rating 94V-O)
|
|
Stand Material
|
PBT
|
|
Core Material
|
Ferrite Core; Silicon Steel Core(CRGO); Nickel alloy; Nanocrystalline Core
|
|
Inner Structer
|
Clamp Design
|
|
Application
|
Cable Tie Fixed
|
|
Working Temperature
|
-25 ~ 75°C
|
|
Environmental Humidity
|
≤ 85%
|
|
Output Connection
|
To be defined
|
Product Specification:
We supply including Nanocrystalline Cut Core and Split current transformers.
Regarding split core current transformers, flexible shape design are supported. Split Core Current Transformer Product list download here.
To confirm your products details, please advise following information:
1. Mini Hole Size
2. Current Input
3. Current Output / Voltage Output
4. Accuracy
5. Lead Wire Length
Main Application:
Our Split-core current transformer can be mounted to existing panels, such as control centers or load centers, to measure or monitor wattage. Which is widely used for:
-
Current Measurement
-
Electrical loading monitoring
-
Energy and sub-metering products
-
Network equipment
-
Instruments and sensors
-
Control System
-
Go GREEN initiatives
