14 Ton Transportation Isuzu Hydraulic Knuckle Truck Mounted Crane
14 Ton Transportation XCMG Hydraulic Knuckle Boom Truck Mounted Crane
- Name: Knuckle boom crane, Lorry mounted crane, Cargo crane truck, Truck loader crane, Hydraulic truck crane
- Max Lifting Capacity: 14 ton
- Max Lifting Moment: 35 t.m
- Max Oil Flow of Hydraulic System: 63 L/min
- Max. Lifting height: 14meters
- Brand: XCMG
- Crane Weight: 4800 kg
- Oil Tank Capacity: 220 L
- Feature: Safety transportion, driven by hydraulic, move fast, The raise and down are driven by wire rope.
- Application: used in Commercial, transportation, oil, balance check, telecommunications, electricity, municipal services and other occasions.
Description:
Knuckle boom crane, help you loading goods on your truck. The crane will fold to compact size after working and will not affect the space of the carriage. The arms are driven by hydraulic, move fast, more effective. The arms can easy to reach narrow spaces like inside the workshop. More accessories like fork, grab bucket, can be attached for different goods loading.
Knuckle boom crane SQ14ZK4Q is lifting capacity is 14tons, moment is 35 T.M.
Applications:
It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.
Knuckle boom cranes can be configured to do just about any job imaginable, from delivering products to cleaning up debris after the job is done.
Specifications:
Model
|
SQ14ZK4Q
|
Unit
|
Max Lifting Moment
|
35
|
t.m
|
Max Lifting Capacity
|
14000
|
kg
|
Recommend Power Needed At Recommend Oil Flow
|
32
|
kw
|
Max Oil Flow of Hydraulic System
|
63
|
L/min
|
Rated Pressure Of Hydraulic System
|
26
|
MPa
|
Oil Tank Capacity
|
220
|
L
|
Rotation Angle
|
(360°) All Rotation
|
.
|
Crane Weight
|
4800
|
kg
|
Installation Space
|
1300
|
mm
|
Choice of Chassis
|
ISUZU
|
SQ14ZK4Q Lifting capability diagram
|
Working radius(m)
|
2.5
|
4.046
|
5.826
|
7.646
|
9.516
|
11.4
|
Lifting capacity(kg)
|
140000
|
8400
|
5478
|
4080
|
3148
|
245
|
Optional parts:
1, Moment limited device
2, Remote control equipment
3, Anti-overwind magnet valve
4, High seat on column
5, Work light
6, Assistant stabilizer leg
Stabilizer leg
|
Spread
|
Fixed
|
2179mm
|
Single extension
|
2256-3556mm
|
Double extension
|
2212-4752mm
|
