Material:
Material thickness:0.7-1.2mm
Applicable material:Al-Mg-Mn alloy plate
Machine Speciafication
|
Main Specification
|
Applicable Working Range
|
|
Motor
|
4KW
|
Minimum Radius of Forward
|
1.0mm material can be 1.5M
|
|
Hydraulic Motor for Cutting
|
2.2KW
|
Maximum Radius of Backward
|
5M
|
|
Forming Station
|
3
|
Sector Minimum Width
|
230mm
|
|
Shafts
|
CR12 with hard Chrome Coated, heat treatment
|
Sector Maximum Width
|
600mm
|
|
Control System
|
PLC
|
Sector Minimum Radius
|
3M
|
|
Forming Speed
|
About 12m/min
|
|
|
|
Machine Size
|
1.3M * 1.3M * 1.8M
|
|
|
