STM8S003F3P6 STMicroelectronics Microcontrollers
Parameter
| Manufacturer |
STMicroelectronics |
| Product Category |
8-bit Microcontrollers - MCU |
| Series |
STM8S003F3 |
| Mounting Style |
SMD/SMT |
| Package / Case |
TSSOP-20 |
| Core |
STM8 |
| Program Memory Size |
8 kB |
Data Bus Width
|
8 bit
|
ADC Resolution
|
10 bit
|
Maximum Clock Frequency
|
16 MHz
|
Number of I/Os
|
16 I/O
|
Date Ram Size
|
1 kB
|
Supply Voltage - Min
|
2.95 V
|
Supply Voltage - Max
|
5.5 V
|
Minimum Operating Temperature
|
- 40 C
|
Maximum Operating Temperature
|
+ 85 C
|
Packaging
|
Reel/Cut Tape
|
Data RAM Type
|
EEPROM |
Interface Type
|
I2C, SPI, UART
|
Number of ADC Channels
|
5 Channel
|
Product Type
|
8-bit Microcontrollers - MCU
|
Program Memory Type
|
Flash
|
Package Quantity (Bag/Roll/Tray/Tube)
|
2500 pcs
|
Subcategory
|
Microcontrollers - MCU
|
Introduction
STM8S003F3P6TR is a microcontroller unit (MCU) from the STM8S series, which is manufactured by STMicroelectronics.
This MCU is based on an 8-bit STM8 core and has a clock speed of up to 16 MHz. It has 8 KB of flash memory for storing program code and 1 KB of RAM for data storage. It also has a wide range of peripheral interfaces, such as UART, SPI, I2C, and ADC.
The "F3P6TR" in the part number indicates the device's package type, which is a 20-pin TSSOP package with a temperature range of -40°C to 85°C. The "STM8S003" indicates the device's family and size.
Overall, STM8S003F3P6TR is a low-cost and versatile MCU suitable for a wide range of applications, including home automation, industrial control systems, and consumer electronics. It is ideal for applications that require low power consumption and low cost and can be used in smart home devices, sensors, and other low-power applications. Its compact package size and low cost make it an excellent choice for cost-sensitive applications that require basic microcontroller features.
Application
STM8S003F3P6TR is a low-cost and versatile microcontroller unit with an 8-bit STM8 core, 8KB flash memory, and 1KB RAM. It has a wide range of peripheral interfaces such as UART, SPI, I2C, and ADC, making it suitable for home automation, industrial control systems, and consumer electronics. This MCU is ideal for applications that require low power consumption and low cost and can be used in smart home devices, sensors, and other low-power applications. Its compact package size and low cost make it an excellent choice for cost-sensitive applications that require basic microcontroller features. Overall, STM8S003F3P6TR is a reliable and versatile microcontroller suitable for a wide range of industry applications. It can be used in a variety of applications, including smart lighting, remote controls, and security systems in the home automation industry. In industrial control, it is suitable for simple monitoring and control applications. In consumer electronics, it can be used in low-power devices like fitness trackers, smartwatches, and remote controls.
Packaging
All integrated circuits are in original factory packaging.
