Street Sweeping Vehicle Isuzu for sale
Applications:
Street sweeper trucks Isuzu (also called Sanitation vacuum sweeper truck, brand new sweeper truck, road sweeper vehicle, road sweeper manufacturers, dust cleaner road sweeper truck) adopts the way of suction and sweeping combination, wet dust removal, electro-hydraulic control and hydraulic dumping unloading to clean the road.
With the structure of four mid-mounted disk brushes and one rear-mounted suction nozzle, which provide a large sweeping width, high sweeping efficiency and good traffic ability. Also convenient for adjustment and maintenance of sweeper device and nozzle.
An automatic clutch is set up on the transmission between the vice-engine and the fan, which can ensure the automatic separation of the vice-engine from the fan when the vice-engine startup or shutdown. Also simplified the operation, reduced the impact on vice-engine and improved the reliability and service life of vice-engine.
The sweeping disk has the protection function and automatic reset function, which can avoid obstacles automatically and return automatically.
Key Features:
---- ISUZU chassis, perfect performance
---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Dustbin tank capacity from 3 to 15 Cublic Meter.
---- Easy operation and easy maintenance.
---- More customer wished equipment are available.
Specifications:
|
Truck mounted road sweeper Isuzu (3+1)
|
|
General
|
Vehicle Brand
|
POWERSTAR
|
|
Chassis Brand
|
ISUZU
|
|
Overall Dimension
|
5450 * 1980 * 2430 mm
|
|
GVW / Kerb Weight
|
7,000kg / 3,350kg
|
|
Cab
|
Cab Capacity
|
2 persons allowed
|
|
Air Conditioner
|
Heating/cooling air conditioner
|
|
Engine
|
Fuel Type
|
Diesel
|
|
Engine Brand
|
ISUZU
|
|
Power
|
98 HP (72 KW)
|
|
Displacement
|
2799ml
|
|
Emission Standard
|
Euro IV or V
|
|
Chassis
|
Drive Type
|
4X2, (left hand drive)
|
|
Transmission
|
ISUZU MSB 5 speed levers with 1
reverse
|
|
Wheelbase/No. of axle
|
3815 mm / 2
|
|
Tire Specification
|
7.00-15
|
|
Tire Number
|
6 tires and 1 spare tire
|
|
Max Speed
|
95 km/h
|
|
Paint
|
Metallic paint
|
|
Superstructure
|
Dustbin Tank
|
3 cbm
|
|
Water Tank
|
1 cbm
|
|
Sweeping width
|
3 Meter
|
|
Sweeping speed
|
3~20 km/h
|
|
Gutter brooms
|
4 sets
|
|
Control system
|
Electrically Hydraulic control
|
|
Control panel
|
English or Your language
|
|
All standard accessories: Back-up alarm,Ladder, warning lights, fire extinguisher, basic tool kit, English manual……
|
|
Optional
|
** Back alarm and Camera can be equipped.
** High-pressure water jetting system.
** Square body or ARC body.
|
---- SGS, BV, CONTECNA, CE Qualified.
---- Local engineer training support.
