Type designation
|
SG3.0RS
|
SG3.6RS
|
SG4.0RS
|
SG5.0RS
|
SG6.0RS
|
|
Input (DC)
|
|
Recommended max. PV input power
|
4.5 kWp
|
5.4 kWp
|
6 kWp
|
7.5 kWp
|
9 kWp
|
|
Max. PV input voltage
|
600 V
|
|
Min. operating PV voltage / Start-up input voltage
|
40 V / 50 V
|
|
Rated PV input voltage
|
360 V
|
|
MPP voltage range
|
40 – 560 V
|
|
No. of independent MPP inputs
|
2
|
|
Default No. of PV strings per MPPT
|
1
|
|
Max. PV input current
|
32 A (16 A / 16 A)
|
|
Max. DC short-circuit current
|
40 A (20 A / 20 A)
|
|
Output (AC)
|
|
Rated AC output power
|
3000 W
|
3680 W
|
4000 W
|
5000 W*
|
6000 W
|
|
Max. AC Output power
|
3000 VA
|
3680 VA
|
4000 VA
|
5000 VA*
|
6000 VA
|
|
Rated AC output current (at 230 V)
|
13.1 A
|
16 A
|
17.4 A
|
21.8 A**
|
26.1 A
|
|
Max. AC output current
|
13.7 A
|
16 A
|
18.2 A
|
22.8 A**
|
27.3 A
|
|
Rated AC voltage
|
220 / 230 / 240 V
|
|
AC voltage range
|
154 – 276 V
|
|
Rated grid frequency / Grid frequency range
|
50 Hz / 45 – 55 Hz, 60 Hz / 55 – 65 Hz
|
|
Harmonic (THD)
|
< 3 % (at rated power)
|
|
Power factor at rated power / Adjustable power factor
|
> 0.99 / 0.8 leading – 0.8 lagging
|
|
Feed-in phases / Connection phases
|
1 / 1
|
|
Efficiency
|
|
Max. efficiency
|
97.9 %
|
|
European efficiency
|
97.0 %
|
97.0 %
|
97.2 %
|
97.3 %
|
97.5 %
|
|
Protection
|
|
Grid monitoring
|
Yes
|
|
DC reverse polarity protection
|
Yes
|
|
AC short-circuit protection
|
Yes
|
|
Leakage current protection
|
Yes
|
|
Surge Protection
|
DC type II / AC type II
|
|
DC switch
|
Yes
|
|
PV string current monitoring
|
Yes
|
|
Arc fault circuit interrupter (AFCI)
|
Optional
|
|
PID recovery function
|
Yes
|
|
General Data
|
|
Dimensions (W*H*D)
|
410 * 270* 150 mm
|
|
Weight
|
10 kg
|
|
Mounting method
|
Wall-mounting bracket
|
|
Topology
|
Transformerless
|
|
Degree of protection
|
IP65
|
|
Operating ambient temperature range
|
-25 to 60 ℃
|
|
Allowable relative humidity range (non-condensing)
|
0 – 100 %
|
|
Cooling method
|
Natural cooling
|
|
Max. operating altitude
|
4000 m
|
|
Display
|
LED digital display & LED indicator
|
|
Communication
|
Ethernet / WLAN / RS485 / DI (Ripple control & DRM)
|
|
DC connection type
|
MC4 (Max. 6 mm²)
|
|
AC connection type
|
Plug and play connector (Max. 6 mm²)
|
|
Grid compliance
|
IEC/EN62109-1/2, IEC/EN62116, IEC/EN61727, IEC/EN61000-6-2/3, EN50549-1,
AS4777.2, ABNT NBR 16149, ABNT NBR 16150, UNE 217002:2020, NTS V2 TypeA,
CEI 0-21:2019, VDE0126-1-1/A1 (VFR-2019), UTE C15-712, C10/11, G98/G99
|
|
Grid Support
|
Active & reactive power control and power ramp rate control
|
