Channeling machine for cylindrical supercapacitor and 18650 lithium-ion battery
SPECIFICATIONS
Functional overview
The machine is suitable for the channeling of cylindrical supercapacitor and cylindrical battery case,and also used for
cylindrical batteries of different specifications, such as 18650 cylindrical battery case after change of some clamps.
Functional characteristics
1.Adopt PLC and pneumatic electromagnetic valve control
2.Composed of feeding/discharging chute, idler wheel, auxiliary flat wheel,rotary spindle bracket, and other systems.
3.Operation is simple, and maintenance is convenient
Technical parameters
|
Applicable case diameter
|
Φ20~120mm(customized)
|
|
Applicable case height
|
50~250mm(customized)
|
|
Capacity
|
About 20ea/min
|
|
Air source
|
0.4~0.7M Pa
|
|
Power source
|
AC380V/50Hz Total power:1kW
|
|
Overall dimensions(LxWxH)
|
1000 x 500 x 1350mm
|
