| Performance Parameter | |
| Light Sources | 617nm LED Aimer ,white LED |
| Supported symbologies |
1D:UPC,EAN, Code128, ISBT 128,Code39,Code93, Full ASCII,Code32,Code11,Matrix 2 of 5 ,Interleaved 2 of 5,Discrete 2 of 5,Codebar,MSI, China Postal,GS1 Databar，Korean Postal,etc 2D:PDF417,MicroPDF417,Data Matrix , Maxi code, QR Code, Micro QR, Aztec, Hanxin, etc 2D:PDF417,MicroPDF417,Data Matrix , Maxi code, QR Code, Micro QR, Aztec, Hanxin, etc 2D:PDF417,MicroPDF417,Data Matrix , Maxi code, QR Code, Micro QR, Aztec, Hanxin, etc |
| Scan Mode | Manually /Automatic inductive |
| Precision | 4mil(Code39),7.5mil(Data Matrix),5mil(PDF 417) |
| Depth of scan field | Horizontal: 46.1°；Vertical：30.4° |
| Optical System | 752H*480V pixels(Wide VGA) |
| Visual Indicator | Buzzer, LED |
| Interface | USB-HID,USB-COM,RS232 |
| Physical Parameters | |
| Dimensions | 96mm*108mm*150mm |
| Weight | 320g |
| Material | ABS+PC |
| Cable length | 2m |
| Color | White, Black |
| Environmental Parameters | |
| Operating Temperature | 0℃ - 50℃ |
| Storage Temperature | -40℃-70℃ |
| Humidity | 0% to 95% RH.Non-condensing |
| Shock Resistance | 1.5m drops to concrete |
| Electrical Parameters | |
| Voltage | Operating DC5V ±1% |
| Current | Operating 400mA |
