Product Description
The LIM, PTM, and SIM modules reside in a dedicated module mounting unit chassis (MMU). The PTM is connected to the LIM via a direct-memory-access ribbon cable. The PTM stores data and then transfer it to the SIM for sending to the Driver. The three modules form a Plant Loop node. The NSIM01 is connected to an NTCU01 termination unit that provides two RS232 serial ports. The Driver connects to one of these serial ports, communicating at a rate of up to 19,200 Baud.
Specification
OEM No/Model: AI921
Market Type: After Market
Packing: FACTORY SEAL
Samples: Not Available
Delivery Time: 1-3 Days
Place of origin: Sweden
Price Terms: FOB
Delivery Port: XIAMEN
Minimum Order: 1 piece/Pieces
