Parameter
Cutting accuracy: ±10mm/m
Diagonal precision: ±0.2mm/m
Cutting maximum size: 1180×1180mm（Special specifications can be customized according to customer needs）
Cutting minimum size: 20*20mm (Can be customized to a smaller size)
Cutting thickness: 2－25mm
Cutting efficiency: 1-2 gigabytes per minute
Cutter life: 3-5 m (straight line conventional cutting)
Operator: 1-2 people
Use of instructions
Cutter box adjustment
Place small glass under the cutter wheel, the upper limit screw is loosened and limit screw is rotated, the angle between the low end of knife box and glass surface is 60°－75°, and then the position limiting screw is tightened. In addition, the cutting pressure can be adjusted by the knurling mother in the lower part of the rotary cutter box.
